    SUS 304 / 316 Sprite Coca Cola Energy Carbonated Drink Filling Line

    Ask Lasest Price
    Brand Name : BOTTLING MACHINERY
    Model Number : DCGF40-40-12
    Certification : CE/ISO9001-2008
    Price : 70000-71000USD
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3sets per month
    Delivery Time : 25-30 working days
    • Product Details
    • Company Profile

    SUS 304 / 316 Sprite Coca Cola Energy Carbonated Drink Filling Line

    Description of SUS 304 / 316 sprite coca cola energy carbonated drink filling line

    Bottle washing part:
    It is mainly composed of a bottle clamping head, an upper disc and a guide rail. The bottle clamping head rotates with the upper disc. The bottle opening clamp is opened by the shaped plate to clamp the filling bottleneck. It is turned 180 degrees according to the guide rail, rinsed and dripped dry. , Then flip 180°%
    Carbonated drink balance pressure filling part:
    It is mainly composed of water tank, filling valve, guide rail, card bottle lifting device, etc.
    It is fed into the filling machine by the bottle card board, the bottleneck is supported by the bottle filling board, and it rotates with the water tank, etc., and slides up on the guide rod according to the guide rail to open the filling valve for filling. After filling, it drops and leaves the filling. The filling valve closes by itself. The bottle is sent out of the filling machine with the card bottle board.
    Bottle capping part
    It is composed of three major parts: a cap separator, a cap screwing machine and a cap sorter.
    There are two types of cap sorting devices: ordinary caps and sports caps. This equipment can be compatible to complete the capping function of the two types of caps.
    It is sent by the bottle card board to complete the card cover, and then sent out by the bottle card board after screwing the cap.
    Equiment list of 15000BPH 3 in 1 40-40-12 Carbonated soft drink filling machine:

    4.1

    Monoblock 3 in 1 washer-filler-capper unitDCGF40-40-124800*3800*26501set
    4.1.1Air conveyorFS-14m1set
    4.1.2Belt conveyorSYS-110m1set
    4.1.3Light checkerDJ-110001pc
    4.1.4Cap elevatorTSJ-1600*600*25001set
    4.1.5cap washing machineXGJ4000*600*18001set
    4.2Pasteurizing tunnel -Bottle warmerPL-1212000*1500*20001set
    4.3Bottle dryerCG-21200*600*18001set
    All models of our carbonated drink 3 in 1 bottle washing-filling-capping machine:

    Model

    DCGF

    8-8-3

    DCGF

    16-12-6

    DCGF

    18-18-6

    DCGF

    24-24-8

    DCGF

    32-32-8

    DCGF

    40-40-12

    DCGF

    50-50-12

    Washing head

    8161824324050

    Filling head

    8121824324050

    Capping head

    3668101212

    Cpacity

    (500ml)

    1500BPH2000BPH4000BPH6000BPH10000BPH15000BPH18000BPH
    Power33.544.87.68.39.6
    Size(mm)

    2000×14

    20×2200

    2300×16

    00×2500

    2600×19

    20×2550

    3100×22

    00×2800

    3850×30

    00×2850

    4850×38

    00×2750

    5750×35

    50×2750

    Weight2300KG2800KG3650KG4800KG6800KG8650KG10500KG
