Description of 1000BPH 4 head semi auto PET / glass bottle carbonated drink
filling line
Principle of 1000BPH 4 head semi auto PET / glass bottle carbonated
drink filling machine:
The machine applies pressure filling method, filling cup will
control filling volume;
Worker open gas nozzles to set volume, then put bottle to filling
head, press release for filling start, worker take off fulfilled
bottles after filling finish;
There are 4 filling heads for the machine; There is enough space
for bottle diameter and height change; Bottle neck size need to be
fixed before machine making. Filling volume can be adjusted by
filling cup. It need to work together with carbonated mixer for
pressure or pump and high position tank. It will need gas pressure
to keep balance pressure.
The four head semi-automatic filling equipment has the advantages
of small volume, reasonable design, simple and compact machine
structure, easy operation and easy replacement of processing parts.
It is suitable for small individual filling companies, especially
for small craft beer equipment.
It is mainly used for carbonated beverage filling, suitable for
glass bottles, PET bottles and various plastic bottles. It is
especially suitable for carbonated drinks containing syrup
Precision multi control valve: stable, high quality, convenient
Food grade stainless steel: hard, tightly combined
Beer bottle holder: stable operation, strong support ability
Pneumatic pedal: controlled by pneumatic components, easy to
operate
Compressed air dial: clear description and precise instrument
Main technique data of 1000BPH 4 head semi auto PET / glass bottle carbonated drink filling
machine:
| Product name | Semi-auto filling machine |
| Model: | BZDG-4A |
| Filling range: | 0.5-2L |
| Precision: | 99% |
| Capacity: | 15-20bpm |
| Suitable bottle | Height: 120-360mm, diameter: 30-105mm |
| Power: | 0.1KW |
| Size: | 1360*700*1820mm |
| Weight: | 300kg |
