Description of Auto carbonated soft gas soda drink tin / aluminum cans filling
machine
The can gas liquid filling machine is an equipment developed on the
basis of digesting and absorbing domestic and foreign cans filling
and sealing machines. The can gas liquid filling machine for canned
gas beverages adopts the principle of balance pressure filling.
When the empty tank enters the lifting tray via the dial, the
filling valve is aligned with the empty tank, the empty tank is
raised and sealed, and the valve port of the filling valve is
automatically opened at the same time. When the filling liquid
level blocks the valve's return pipe port Stop filling at the time.
The filled can is sent to the sealing machine head through the hook
chain, and the lid is sent to the can mouth by the cap feeder and
the pressure head. When the can supporting mechanism is raised, the
pressure head presses the can mouth, and the sealing wheel is
pre-sealed and then solidified. After the can is sealed, it is
pushed out by the head of the capping mechanism, and then enters
the can-out transport.
Blow-drying machine: This machine is a can blow-drying equipment
developed and produced by our company. It is used to blow-dry the
cans and bottles on the production line. then It is convenient for
labeling, spraying and packaging. Suitable for a wide range of tank
types, convenient operation and low energy consumption. It can be
used in various canneries, wineries, breweries, beverage factories
and pharmaceutical factories.
Coding equipment: It is used to print the current production date
on can, bottled water, and is divided into inkjet printers and
laser printers.
Equipment list of 18 head 2 in 1 balance pressure can filling
machine:
| 1.1 | Semi auto can depalletizer | SXDJ | 2500*1500*2500 | 1set |
| 1.2 | Tunnel type can washer | XG-1 | 1500*300*1500 | 1set |
| 1.3 | Monoblock beer can filler-sealer | BGF18-4A | 2100*1800*2000 |
1set |
| 1.3.1 | Inlet belt conveyor | SYS-1 | / | 2m |
| 1.3.2 | Outlet belt conveyor | SYS-1 | / | 4m |
| 1.3.3 | Light checker | DJ-1 | / | 1set |
Features of the 4 head sealer:
1, Ingenious lid loading device to make sure no can, no lid
loading, no sealing;
2, Energy saving model, one motor can process all actions;
3, Full sealing effect make sure to be suitable for liquid packing
can;
4, The machine suitable for all kinds of cans with same diameter,
height can be adjusted easily;
5, Twice sealing tech to make well sealing effect, no leakage;
6, Sealing wheel lift time can reach 5 million times
7, Easy adjusting wheel for changing different height cans very
easy
Please check the details of 18 heads of filler:
