Description of Bottle turnover / inverse / reverse cap sterilizer for juice
bottling line
The principle of Bottle Reverse sterilizer:
bring filled-capped bottles in inclining position, use the liquid
itself temp to do 2nd sterilizing to caps, and at the mean time to
soften sealing pad inside cap, enhance sealing tightness between
bottle and cap to make sure product quality .
The body material is SUS304; The transportation is by
heat-resistant plastic chain and stainless steel chain.
It solves the incomplete sterilization of bottle caps in other
ways. It uses high-temperature materials to pasteurize the bottle
caps once. The sterilization time is adjustable. The whole machine
is made of stainless steel, imported heat-resistant anti-skid chain
plates, and has high operating reliability. . The bottle inverting
sterilizer is mainly used to sterilize the unsterilized or
high-temperature processed parts of the bottle mouth and the inner
wall of the bottle cap after hot filling of juice, tea and other
beverages packaged in PET polyester bottles. This machine is mainly
composed of conveyor chain system, bottle reversal chain system,
frame, bottle reversal guide rod, etc.; this machine realizes
automatic reversal sterilization and self-reset, and during the
sterilization process, only the high temperature of the bottle
contents Sterilize the bottle mouth and the inner wall of the
bottle cap without adding any heat source to achieve the purpose of
energy saving. The body is made of SUA304 material, which is
beautiful and easy to use. The output is 5000-20000 bottles/hour,
and the sterilization time is 15-40 seconds for users to choose.
This machine is mainly used to sterilize the gap between the bottle
mouth and bottle cap that cannot be contacted by high-temperature
materials after hot filling and capping of tea and fruit juice
beverages. After filling and capping, the machine will
automatically turn over 90 to lay the bottle flat. The inner wall
of the cap will be sterilized by the material temperature and enter
the spray cooling machine. The machine adopts imported transmission
chain, which is stable and reliable, and does not damage the bottle
body. , The transmission speed can be adjusted steplessly.
Advantage of Bottle Reverse sterilizer:
1, It can be used for various of bottle shapes and volumes;
2, Easy construction for easy maintenance;
3, Speed and sterilizer time adjustable;
Parameter of Bottle Reverse sterilizer:
Capacity:0-10000BPH
Available inverse time :28～30s adjustable
Inverse angel:90°
Bottle distance:76.2mm
Applicable bottle:Dφ50-φ95mm H:150-340mm
Consumption:0.75KW
Weight:800kg
Inverse Dimension: 4000*800*1200mm
Total dimension: 5000*800*1200mm
The Bottle Reverse sterilizer used in the juice bottling line:
| Items | Description | Model | Size-mm | Qty. |
| 1.1 | Reverse sterilizer | DP-4 | 4000*800*1200 | 1set |
| 1.2 | Cooling pasteurization tunnel | PL-6 | 6000*1500*1800 | 1set |
| 1.2.1 | Cooling tower | 100T | ￠2180*2690 | 1set |
| 1.3 | Bottle Blow Dryer | CG-1.2 | 1200*600*1800 | 1set |
