Description of 2400BPH 2 blowers 1 preform heater 1L bottle blow molding machine

BL-1200B 2400BPH semi automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 10-2000ml. The capacity is 2400bottles per hour(based on 500ml bottle)It is widely used to produce the water bottle, carbonated bottle, pesticide bottle, oil bottle cosmetics, wide-mouth bottle etc.

1, What's the volume of your bottles? please provide the pictures and specifications if you have.
2, About the speed, how many bottles do you need to make per hour?
3, Do you need automatic type or semi-automatic type?
The video https://youtu.be/Y2-wI5-qrfE is our most popular 1200BPH semi-automatic PET bottle blow molding machine for 0-2L bottle

Equipment list of BL-1200B 2400BPH semi automatic bottle blow molding machine:

Main parameter:
Model	BL-1200B
Container	Product material	PET,PP
	Volume	0.1-2
	Theoretical output	2400BPH
	Preform length	15-350
	Preform inner diameter	Φ5-38
Moulding	Max.mould plate Dimension (L x W)	350×380
	Max.mould thickness	180
	Clamping force	45
	Mould opening stroke	16
Machine size and weight	Main machine (L x W x H)	160×60×161cm
	Main machine weight	500
	Heater (L x W x H)	187×63×145cm
	Heater weight	250
	Power	17.5

HP air compressor:

Air compressor	Unit	1.2M3/30KG
Volume	M3	1.2
Pressure	Kg	30
Speed	r/min	800
Power	KW	15
Overall Dimension	mm	1880×850×1050
Weight	kg	580

ZhangJiaGang City BOTTLING Machinery Co.,Ltd. which was originally set up as an factory in 2011,the company is growing up time by time in research and design, quality and production, sales and after sale service. Our machineries are sold to more than 50 countries in the world and over cross domestic.

We specialize in producing beverage filling-packing equipments and water treatment equipments. The quality already pass drinkable standard.At present we produce: production lines for mineral water, pure water, fruit juice,tea drink,milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 60-1200 barrels per hour and water treatment plants 1-30 ton/hour; We provide separate machinery or turnkey project.

Our products pass quality inspection executed by Bureau of Quality and Technical Supervision every year. We pass Italy CE inspection in 2011;

We have full-time development and design engineer team, we absorb technologies from Germany, Japan, France, Italy, Switzerland, combined with China's national conditions to develop high starting point and advanced technology filling equipments, degree of automation to achieve the advanced level.

We own 3700 square meters modern factory in accordance with ISO9001: 2000 certification system standards with all kinds of advanced processing equipment and testing equipment, experienced technicians, scientific and strict management, all constitute BOTTLING excellence in product manufacturing system, which provides the strongest protection for BOTTLING product quality.

We believe in BOTTLING’s future while you choose us!
