Description of 2000BPH hand input feeding open mouth bottle 2 cavity blow molding
machine
This machine is suitable for the production of wide mouth bottles.
It has two blowing cavities, and the output is 2000bph. It is
suitable for 0.1l-2l bottles. It is widely used in pet cans, juice
wide mouth bottles, medicine wide mouth bottles, purified water
wide mouth bottles, etc.
Heating tunnel:
-Reasonable ventilation and cooling system can fully ensure the
preform heating and the stable cooling of the container mouth.
-PLC independent segmented temperature control, reasonable drying
tunnel world, can be flipped, and the front and back up and down
are reliable.
-The preform heating center distance is small, the heating speed is
fast, and the energy saving is 40% compared with the ordinary
heating system.
-The bottle preform enters the oven, and the bottleneck is upward.
Due to the efficient oven cooling and ventilation system, the
bottleneck and shaft will not be overheated. The surface of the
preform can be cooled well, even thick preforms and
high-productivity products can be avoided. Be crystallized.
Clamping mechanism:
-The mold clamping mechanism adopts a five-point double-crank mold
clamping mechanism, optimized design, large clamping force and fast
speed.
-The revolving slider is driven by the servo to quickly send the
heated preform to the mold for blow molding.
-After heating, the preform leaves the oven and is transferred to
the blowing mold via a servo motor.
The integral air valve is used for pre-blowing, blowing and taking
out, so it is necessary to ensure rapid, accurate and repeated
adjustment of the blowing equipment, taking into account the
flexibility of the blowing process.
Equipment list of 2000BPH Automatic open mouth bottle Hand input
blow Molding Machine:
| Items | Name of machine | Model | Size(mm) | Qty. |
| 2.1 | Hand input blow Molding Machine | 2cavity | 2880*1580*1800 | 1set |
| 2.2 | HP Air Compressor | 1.2 m3/ min 30Kg | 2000*1100*1600 | 1set |
2.3 | LP Air Compressor | 1.6 m3/min 10Kg | 2000*1050*1900 | 1set |
| 2.4 | Air dryer | 2.0 m3/min 30Kg | 1050*650*1100 | 1set |
| 2.5 | Air Filters | 2.0 m3/min 30Kg | 750*350*350 | 2sets |
| 2.6 | Blow mould | 50ml-500ml | 2cavity | 1set |
Parameters of 2000BPH Automatic open mouth bottle Hand input blow Molding Machine:
Capacity: 1500-2200pcs/h
Power: 23KW
Max applicable bottle volume: 2000ml
Max bottle diameter: 95mm
Working pressure: 7Mpa
Blowing pressure: 30Mpa
Dimension: 2880*1580*1800mm
Weight: 1500kg
