Principle:

Cans will go to the can sealing machine through conveyor. The 6 station dia plate will turn the cans under lid loading head , the lid will be loaded on can mouth automatically with the can body triggering. With the motor driven energy, the can which already be loaded with lid will go forward to sealing position. With the lifting cam, the sealing head can go up and down when cans come and go. The sealing head will go down to press on the can when the cans come; The sealing head are composed with 4 groups of sealing wheels around one circle, the 4 groups of wheels will turn rapidly together with sealing head in the same direction to process sealing job. The whole system will finish edge rolling job.

The sealing wheels are in 2 step sealing model to make sure the the can edge and lid edge close tightly. Then the sealed can will be suitable for all kinds of liquid, no leakage.

The machine adopts drehstrom asynchronous motor Y802-4 at 1390r/min, with deceleration by triangle belt pulley and turbine, the speed changes to 40r/min.Whole machine is made by SUS304.

Characters:

1, Ingenious lid loading device to make sure no can, no lid loading, no sealing;

2, Energy saving model, one motor can process all actions;

3, Full sealing effect make sure to be suitable for liquid packing can;

4, The machine suitable for all kinds of cans with same diameter, height can be adjusted easily;

5, Compact construction, only need small space to use the machine;

6, Delivered with whole machine, no need commissioning again after delivery;

ZhangJiaGang City BOTTLING Machinery Co.,Ltd. which was originally set up as an factory in 2011,the company is growing up time by time in research and design, quality and production, sales and after sale service. Our machineries are sold to more than 50 countries in the world and over cross domestic.

We specialize in producing beverage filling-packing equipments and water treatment equipments. The quality already pass drinkable standard.At present we produce: production lines for mineral water, pure water, fruit juice,tea drink,milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 60-1200 barrels per hour and water treatment plants 1-30 ton/hour; We provide separate machinery or turnkey project.

Our products pass quality inspection executed by Bureau of Quality and Technical Supervision every year. We pass Italy CE inspection in 2011;

We have full-time development and design engineer team, we absorb technologies from Germany, Japan, France, Italy, Switzerland, combined with China's national conditions to develop high starting point and advanced technology filling equipments, degree of automation to achieve the advanced level.

We own 3700 square meters modern factory in accordance with ISO9001: 2000 certification system standards with all kinds of advanced processing equipment and testing equipment, experienced technicians, scientific and strict management, all constitute BOTTLING excellence in product manufacturing system, which provides the strongest protection for BOTTLING product quality.

We believe in BOTTLING’s future while you choose us!
