Features of BL-3850 Automatic 5 gallon preform injection molding machine:

A, Injection Unit

• A01) Five Stage Injection Pressure

• A02) Five Stage Injection Speed

• A03) Programmable Holding Pressure profile

• A04) Refilling in Stages

• A05) Controller Inbuilt PID Temperature control

• A06) Feed Zone Temperature indication

• A07) Oil temperature indication

• A08) Adjustable such back before and after refilling

• A09) Auto purge break

• A10) Linear transducer to control programmable injection position

• A11) Cold start screw prevention

• A12) Sliding Mechanism for hopper

• A13) Gas Nitrated hardened screw and Barrel

• A14) Screw back pressure con troll with pressure relief valve

• A15) Hand Operated Lubrication Unit

B. Clamping Unit

• B01) Five Point twin toggle locking system

• B02) Case Hardened toggle, Brackets and links with hardened

PIN & BUSH

• B03) Motorized mould height adjustment for quick mould change

• B04) Auto tonnage setting facility

• B05) Low pressure precise mould protection with pressure and time

setting

• B06) Five stage Mould closing

• B07) Five stage Mould opening

• B08) Hydraulic cushioning for consistent mould opening position

• B09) Linear transducer to control programmable clamp system

• B10) Electrical and hydraulic (Dump value) interlock safety gate

• B11) Moving platen with mechanical support with Teflon

• B12) Hydraulic Ejector with Multi stroke

• B13) Auto lubrication unit

C. Ejector

• C01) Linear transducer to control programmable ejector position

• C02) Multiple stroke ejection

• C03) Ejector forward/ backward speed adjustable

• C04) Ejector forward/ backward pressure adjustable

• C05) Two stage in ejector forward/ backward operation

• C06) Additional safety of sensing ejector backward position with Proximity switch

Equipment list of BL-3850 Automatic 5 gallon preform injection molding machine:

Parameters of BL-3850 Automatic 5 gallon preform injection molding machine:

Preform mold and capacity of BL-3850 Automatic 5 gallon preform injection molding machine:

Water chiller:

Hopper Dryer:

ZhangJiaGang City BOTTLING Machinery Co.,Ltd. which was originally set up as an factory in 2011,the company is growing up time by time in research and design, quality and production, sales and after sale service. Our machineries are sold to more than 50 countries in the world and over cross domestic.

We specialize in producing beverage filling-packing equipments and water treatment equipments. The quality already pass drinkable standard.At present we produce: production lines for mineral water, pure water, fruit juice,tea drink,milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 60-1200 barrels per hour and water treatment plants 1-30 ton/hour; We provide separate machinery or turnkey project.

Our products pass quality inspection executed by Bureau of Quality and Technical Supervision every year. We pass Italy CE inspection in 2011;

We have full-time development and design engineer team, we absorb technologies from Germany, Japan, France, Italy, Switzerland, combined with China's national conditions to develop high starting point and advanced technology filling equipments, degree of automation to achieve the advanced level.

We own 3700 square meters modern factory in accordance with ISO9001: 2000 certification system standards with all kinds of advanced processing equipment and testing equipment, experienced technicians, scientific and strict management, all constitute BOTTLING excellence in product manufacturing system, which provides the strongest protection for BOTTLING product quality.

We believe in BOTTLING’s future while you choose us!
