Description of Linear type automatic 1500BPH juice filling line:

Juice is divided into HPP juice, NFC juice, FC juice, Flavor beverage, Flavor beverage is the most common juice, it is made from juice and some other flavoring materials, then passes through a degasser, homogenizer, UHT high temperature sterilization machine Processing, and the next part is the filling part. The filling machine is different from water filling. The juice filling machine is hot filling, with higher structural requirements. It has a temperature control system to ensure that the juice temperature will not drop. The bottle filled with juice needs to go through a bottle inverting machine and a spray machine. The bottle inverting machine pours the bottle by 90 degrees to let the temperature of the juice sterilize the lid, and the spray machine lowers the temperature of the bottle. The labeling machine and packaging part are behind.

Equipment list of 1500BPH mixing juice filling line:

First part is the RO water treatment system, please check the following parts.

2, 500LPH flavor juice making line:
2.1	Syrup melting pot	300L	φ700*1500	1set
2.2	Juice mixing tank	500L	φ850*1600mm	2set
2.3	Double filter	SL-2	800*350*800	1set
2.4	Homogenizer	JJ500-25	1030*650*1090	1set
2.5	Vacuum degasser	1-2T/h	1200*700*1800	1set
2.6	UHT juice sterilizer	1000L	1000*700*1250	1set
2.6.1	Heat transfer oil heating tank	/	D1200*1850	1set
2.7	Drink pump	/	/	2set
2.8	Sus pipe-connection	DN25	/	1suit
2.9	Aseptic tank	1000L	φ1000*2100	1set
3, 1500BPH flavor juice filling-packing line:
3.1	Linear juice hot filling drink washer-filler-capper	QS-12 RG-12 FXZ-1	/	1set
3.1.1	Light inspector	/	/	1pcs
3.2	Ink jet code printer	OH-338	347*220*100	1set
3.3	Sleeve table+ sleeve shrink tunnel + steam generator	SB-1200	1200*700*2000	1set
3.4	Semi-auto shrink packing machine	5538+5040	3600*950*1680	1set
3.5	Connection conveyor	/	/	1suit

ZhangJiaGang City BOTTLING Machinery Co.,Ltd. which was originally set up as an factory in 2011,the company is growing up time by time in research and design, quality and production, sales and after sale service. Our machineries are sold to more than 50 countries in the world and over cross domestic.

We specialize in producing beverage filling-packing equipments and water treatment equipments. The quality already pass drinkable standard.At present we produce: production lines for mineral water, pure water, fruit juice,tea drink,milk drink and carbonated drink with capacity 1000-20000bottles/hour; production lines for vinegar, soy sauce and wine 1000-20000bottles/hour; 3-5 gallon barreled water with capacity 60-1200 barrels per hour and water treatment plants 1-30 ton/hour; We provide separate machinery or turnkey project.

Our products pass quality inspection executed by Bureau of Quality and Technical Supervision every year. We pass Italy CE inspection in 2011;

We have full-time development and design engineer team, we absorb technologies from Germany, Japan, France, Italy, Switzerland, combined with China's national conditions to develop high starting point and advanced technology filling equipments, degree of automation to achieve the advanced level.

We own 3700 square meters modern factory in accordance with ISO9001: 2000 certification system standards with all kinds of advanced processing equipment and testing equipment, experienced technicians, scientific and strict management, all constitute BOTTLING excellence in product manufacturing system, which provides the strongest protection for BOTTLING product quality.

We believe in BOTTLING’s future while you choose us!
