Description of 18 head beer beverage 500ml tin / PET / aluminum cans filling
machine
The production line of canned beverages mainly includes: water
treatment equipment, beverage mixing system, depalletizer, empty
can washing machine, can filling and sealing machine, sterilization
pot, cage unloading equipment, blow dryer, can turning machine,
inkjet printer , PE film heat shrink packaging machine or carton
packaging machine.
Fully automatic or semi-automatic empty can (bottle) depalletizer:
mainly suitable for automatic depalletizing of three-piece cans,
two-piece aluminum cans and glass bottles. The empty cans (bottles)
stacked on the pallet are pushed up to the conveyor layer by layer,
and then conveyed to the chute type can washer or automatic bottle
washer by a multi-line conveyor or turntable, instead of manual
cans (bottles). ),Increase productivity. PLC programmable computer
automatic controllers, photoelectric switches, travel switches,
pneumatic controls, etc., all adopt well-known brands such as
Germany, Japan, and Taiwan.
Spray can washing machine: It automatically sprays and sterilizes
the inner cavity and outer surface of the can, and the material is
stainless steel. When flushing the cans, first turn the cans into
the can washer, and spray down the side and down through a porous
warm water pipe. The cans will rotate 0.5 meters to achieve the
purpose of cleaning, and then the cans can be turned into the next
conveyor chain. Tao. It is necessary to pay attention to the tank
not to be interrupted in the chute, so as to prevent the fast
irrigation speed and the unclean water control.
Filler
1) Balance filling method.
2) High-pressure foam stimulator is equipped to minimize air
remaining at the neck.
3) Centralized automatic lubrication system, simple for
maintenance.
4) Filling level tolerances : ± 2.0 mm
5) Bottle break rate : max. 0.01% (1:10,000)
6) With perfect CIP cleaning function, and capable of rinsing
filling pipes with acid, lye liquid and hot water.
7) All the materials in contact with the valves, tanks, pipes are
made of stainless steel 304 materials, inside and outside the wall
of mirror-polished, ensuring it is healthy.
Parameters of the whole 18 head 2 in 1 balance pressure can filling
machine:
Power: 4.5KW
Dimension: 2100*1800*2000mm
Weight: 4000kg
Pressure: max 0.4Mpa
Equipment list of the whole 18 head 2 in 1 balance pressure can
filling line:
| Items | Name of machine | Model | Size(mm) | Qty. |
| 1.1 | Semi auto can depalletizer | SXDJ | 2500*1500*2500 | 1set |
| 1.2 | Tunnel type can washer | XG-1 | 1500*300*1500 | 1set |
| 1.3 | Monoblock beer can filler-sealer | BGF18-4A | 2100*1800*2000 |
1set |
| 1.3.1 | Inlet belt conveyor | SYS-1 | / | 2m |
| 1.3.2 | Outlet belt conveyor | SYS-1 | / | 4m |
| 1.3.3 | Light checker | DJ-1 | / | 1set |
| 1.4 | Bottle blow dryer | CG-1 | 1000*600*1800 | 1set |
| 1.5 | Reverse device | / | / | 2sets |
| 1.6 | Ink jet code printer | OH-338 | 347*220*100 | 1set |
| 1.7 | Automatic case erector | EB-10P | 2000*1900*1500 | 1set |
| 1.8 | Automatic case filler (grasper type) | 01GDA | 4900*1200*2100 | 1set |
With 2.4m belt conveyor to connect case erector to case filler for
empty case And with 2.4m bottle division conveyor for bottles incoming |
| 1.9 | Automatic case sealer | FX-6050 | 3720*950*1770 | 1set |
| With 2m roller conveyor for case outlet |
