Brand Name : | BOTTLING MACHINERY |
Model Number : | 3 layers heat mixing tank |
Certification : | CE/ISO9001-2008 |
Price : | 2200-7300USD |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 20sets per month |
Delivery Time : | 25-30 working days |
Capacity | 500LPH | 1000LPH | 2000LPH | 3000LPH | 4000LPH | 5000LPH | 6000LPH |
Material | SUS304 | ||||||
Pressure | 0.6Mpa | ||||||
Structure | inner layer+middle layer+insulation+outer layer | ||||||
Heating way | Steam heating | ||||||
Motor power | 0.75KW | 0.75KW | 1.1KW | 1.5KW | 2.2KW | 3KW | 6KW |
Motor speed | 35RPM | ||||||
Inner thickness | 3mm | ||||||
Middle layer thickness | 1.5mm | ||||||
Insulation thickness | 50mm | ||||||
Outer thickness | 1.5mm | ||||||
Insulation material | Polyurethane foam | ||||||
Manhole diameter | 400mm | ||||||
Diameter of inlet&outlet | 38mm | 38mm | 38mm | 38mm | 38mm | 51mm | 51mm |
Dimension (D*H)(mm) | 800*1000 | 1100*1220 | 1450*1200 | 1600*1500 | 1600*2000 | 1660*2300 | 1800*2400 |
Total Height(mm) | 2100 | 2420 | 2420 | 2700 | 2900 | 3200 | 3300 |
Weight(KG) | 310 | 400 | 600 | 700 | 800 | 900 | 950 |
![]() |
