    15W 10000BPH PET Bottle Date Flying CO2 Laser Code Printer

    Ask Lasest Price
    Brand Name : BOTTLING MACHINERY
    Model Number : D15
    Certification : CE/ISO9001-2008
    Price : 3500USD
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 50sets per month
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    15W 10000BPH PET Bottle Date Flying CO2 Laser Code Printer

    Description of 15W 10000BPH PET bottle date flying CO2 Laser code printer


    Characters of 10000BPH 15W Laser code printer:
    CO2 Laser Printer is designed for production line nonmetal materials marking and some plastic PET bottles marking. For example, drinks expiry date printing, we will install a sensor to give signals back to the laser machine when PET bottles pass by, then start to mark. It can continue to work in a very fast speed. One hour for 15W CO2 Laser Printer can be 10000 bottles. The machine can also marking the objects by meters, we will just fix a length counter. The lifetime can reach 30,000 hours. During the marking process, it won’t cause any consumables, compared to the ink jet printer, it is cost-saving and economical.

    Parameters of 10000BPH 15W Laser code printer:

    ItemParameter
    ModelD15
    TypeCO2 laser code printer
    Application industryFood , beverage , drinks , medical , electric wire , chemical , packing , electron and so on
    Marking materialPET , acrylic , glass , leather , plastic , cloth , carton , rubber and so on . Eg : mineral water bottle , edible oil , wine bottle , food package and so on .
    Laser machine characteristicsMachine materialAll aluminum structure
    Laser output power15W
    Wave length10.6 um
    Marking speed≤7000mm/s
    Control boardIndustrial-grade highly integrated all-in-one motherboard
    operating systemLinux or Windows
    cooling systemAir cooling at room temperature (no need for compressed air)
    Marking systemLaser printer dedicated
    Operating platform10-inch touch screen
    ConnectorSD card interface/USD2.0 interface/communication interface
    Data protectionIn the case of power failure other than the power supply, ensure that user data is not lost
    Lens rotationThe scanning head can be rotated at any angle of 360°
    VoltageAC220V,50-60Hz
    Total power500W
    Protection levelIP54
    Total Weight67KG
    Overall size

    Bracket 400*235*1325mm
    Host 640*455*975mm

    Pollution levelThe marking itself does not produce any chemicals


    Environmental resistance

    Storage temperature-10℃-45℃(No freezing)
    Working temperature
    Storage environment humidity10%-85%(No condensation)
    Working environment humidity
    Lens parametersMarking range≤400*400mm
    Marking typeDot matrix, vector
    Minimum line width0.03mm
    Repeatability0.01mm
    TargetingRed light focus
    Number of marking character linesEdit arbitrarily within the marking range
    Production line speed0-30m/min (Depending on product material and marking content)
    Operation languageChinese and English
    Character typeSupport font typeSingle-line font/double-line font/dot matrix font
    Graphic file formatPLT format vector file input/output
    file formatBMP/DXF/JPEG/PLT
    Graphic elementsPoint, line, arc text, rectangle, circle
    Variable textSerial number, time, date, counter, shift
    Bar codeCode 39 / Code 93 / EAN - 13 / Code 128 and so on
    QR codeQRCode,Data Matrix etc.
    Online editing

    Support online editing of marking information without shutdown
    Software customization

    Software customizationThe software can be customized and developed according to the various control requirements of the customer's production line
    product testingProduct inspection inputNPN/PNP/24V detector
    Product speed detectionNPN/PNP/24V/RS422 synchronizer or synchronization signal
    Communication interconnectionUSDSupport USD file import/export, system backup
    PLC communication inputInterlock input signal, marking start/stop control signal, fault clearing signal
    PLC communication outputLaser ready signal, printing signal, fault output signal
    Technical InformationProvide equipment simple operation manual, detailed software description (CD-ROM)
