Description of Semi-auto wet cold glue paper medicine PE bottle labeling machine
Basic use of Semi-auto wet glue labeling machine:
It is suitable for the paste labeling of various round bottles,
paper separation, gluing, labeling, and labeling are automatically
completed, reducing manual labeling procedures and improving
labeling efficiency. Glue is evenly applied, with filamentous
stripes, no wrinkles, and improves packaging quality. It is
especially suitable for labeling production of small and medium
batches, such as labeling of food and wine.
Features of Semi-auto wet glue labeling machine:
The operation is simple, and the simple operation of manually
loading and unloading bottles can complete the entire labeling
process.
The adjustment is simple, especially suitable for small batch
production. It is simple and quick to switch varieties and label,
which improves efficiency.
Save glue, the thickness of the glue can be adjusted according to
needs, the glue is evenly spread, and glue waste is eliminated.
The labeling is accurate, the overlap of the label head and tail is
high, and the label is positioned accurately on the bottle body.
The labeling quality is high, the silk stripes can be adjusted, the
labeling is flat, no wrinkles, no warpage, and the packaging level
is improved.
Scope of application of Semi-auto wet glue labeling machine:
Applicable label: paper label (paste required).
Applicable products: products that require paste labels to be
affixed to the circumferential surface.
Application industry: widely used in food, medicine, wine and other
industries.
Application examples: food can labeling, wine bottle paste
labeling, glass bottle paste labeling, etc.
working principle of Semi-auto wet glue labeling machine:
＊Core working principle: The equipment gets the signal of placing
the product in place, the equipment automatically separates a
label, and the label is applied to the set position of the product
after being glued. The label is applied and relabeled at the same
time as the product is rotating, and the label is applied and
covered On the product, the attaching action of a label is
completed;
＊Operation process: put the product> paper separation + paper
feeding + glue application + labeling + labeling (automatically
realized by the equipment)> take out the labeled product.
Technological parameter:
Labeling precision: ±1mm Labeling speed: 15-25 b/min
Round bottle type: Dia: 30mm-120mm; Height:30mm-230mm Paper label
type: Length: 80mm-280mm; Width: 40mm-175mm Overall dimension
(L*W*H): 630mm*430mm*330mm
Power: 220V AC 60HZ
Weight: about 37kg
Configuration:
Main machine | Item | Description | Qty. | Material |
| 1 | Feeding mechanism | 1 pc | SUS, Aluminum alloy |
| 2 | Sizing mechanism | 1 pc | SUS, Aluminum alloy |
| 3 | Covering mechanism | 1 pc | SUS, Sponge tube |
| 4 | Base | 1 pc | Aluminum alloy |
5 |
Screw down mechanism |
1 pc |
Aluminum alloy, POM |
6 |
Paper inserting mechanism |
1 pc |
SUS |
| 7 | Leading mechanism | 1 pc | Aluminum alloy |
8 |
Adjustment mechanism |
1 pc | Copper, SUS, Aluminum alloy |
| 9 | Cover frame | 1 pc | Painting metal plate |
