Description of 30W 8000BPH conveyor online glass bottle CO2 Laser code printer
The carbon dioxide laser marking machine adopts an imported
packaged CO2 laser, equipped with a German high-speed scanning
galvanometer and a beam expanding focusing system, with high
marking accuracy and high speed; the height of the laser can be
adjusted up and down, easy to use, and can replace the lenses of
various marking formats ; Long continuous working time, clear and
beautiful marking, powerful software function, serial number
marking, flying marking; fixed laser marking design, simple
operation, perfect upper and lower ventilation system, work
environment-friendly and safe; suitable for all kinds of leather
and leather , Two-color boards, plastics and various solid
materials.
Advantage of 8000BPH Glass bottle carbon dioxide Laser code
printer:
1. The equipment can identify the metal and part of the non-metal
surface with vector patterns, serial numbers, batch numbers,
specifications, etc., in Chinese and English, numbers, and
trademarks.
2. It can realize the mixed layout of graphics, text and numbers
and complete the marking at one time;
3. Realize graphics and other technical parameters that need to be
changed, marking one by one or digital increments, etc.;
4. Suitable for online production of multiple varieties and large
quantities;
5. Realize on-the-fly marking (requires assembly line cooperation).
6. The movable support can mark the workpiece on multiple sides,
and can also mark according to a certain inclination angle.
7. The equipment is small in size and easy to move.
8. When the equipment makes marking on the fly, it is only
necessary to place the equipment in the marking position, and there
is no need to communicate with other equipment.
9. The device also has a communication interface with other
devices, one input signal, one output signal.
Parameters of 8000BPH Glass bottle carbon dioxide Laser code printer:
| Laser type | Metal tube carbon dioxide laser |
| Laser power | 30W |
| Laser head | Length: 750mm Width: 160mm Height: 180mm |
| Whole machine Power | 800W |
| Print line speed | ≤150m/min |
| Number of flight mark lines | 10X 10 |
| Minimum line width | 0.15mm |
| Minimum character | 0.40mm |
| Repeating accuracy | ±0.01mm |
| Laser wave length | 10.6µm |
| Divergence angle miliradian | 7.5mrad |
| Fastest printing line speed | 7000mm/s |
| Number of characters printed per second | 1200bps |
| Focal length | 120mm |
| Rows | Any rows |
| Character height | 0.5~100mm |
| Print information | Line height 0.5-100mm,Max 300mm |
| Print range | 90*300mm |
| Cooling way | Air cooling |
| Environment literature | 5-45℃ |
| Environment humidity | 90% non-condensing |
| Print content | English letter,Arabic numerals and patterns |
| Optimal print interval | ≥1mm |
| Power Supply | Ac 110V-220V/50HZ,5A |
| Humidity | 10%-90% |
| Communication interface | USB,RS232/485,Ethernet |
| Protection degree | IP54 |
| Detection settings | Photoelectric sensor,PNP/12V |
| Size and weight: | Laser head 850*170*195mm 25KG Laser bracket 1500*600*580mm 22KG Controller 275*210*30mm 2KG |
